Description
| Connector and Electrical | Connector Type | 5m cable / Socket / Socket with Shutter |
| Input Voltage | AC220V ±10% (1-phase), AC380V ±10% (3-phase) | |
| Input current | 16A/32A | |
| Rated frequency: | 45-65 Hz | |
| Max Output voltage | AC220V ±10% (1-phase), AC380V ±10% (3-phase) | |
| Max Output Power | 7 kW (1 Phase), 11 kW (3 Phase), 22 kW (3 Phase) | |
| Protection | Ingress Protection | IP55 |
| Impact Protection | IK08 | |
| Leakage protection: | Type B (AC 30 mA + DC 6 mA) | |
| Operating temperature: | -30 to +50°C | |
| Operating humidity: | 5%-95% (no condensation) | |
| Altitude: | < 2000 m | |
| Electrical protection: | Overload, short circuit, over temperature, lightning protection | |
| Certificate | CE, TÜV, UKCA, SASO, IEC 61851 | |
| Functions | Charge Mode | Level 2, Mode 3 |
| Internet connection: | WiFi, LAN, Bluetooth | |
| External communication: | OCPP 1.6J (for shared charging) | |
| Display: | 4.3-inch LCD | |
| Communication protocol: | OCPP 1.6J | |
| Dynamic load balance | Home load balancing (DLE) | |
| Metering | MTD (Metering) | |
| Mechanical | Dimensions product without cable | 350 (H) x 240 (W) x 95 (D) mm |
| Weight gross, kg | 8.0kg(including charging gun) |
Target group:
Wholesalers and retailers: To build own brand.Installers, high qualityto reduce after-sales cost
Mobility services and fleet management companies: Thanks to smartcharging, app control and optional PV integration, you retain fullcontrolover your charging processes at all times.
Real estate and commercial real estate: Shared charging options for residents.
Features:
Flexible power options: With 3.6kW, 7.2kW, 11kW, and 22kW options.
Cable or socket: A charging cable with customized cable length or asocketonly version is available as an option.
IP65-rated: built to withstand dust, heavy rain, and water jets forreliable outdoor use
4.3inch LCD: The big touch screen shows you the charging status clearlyand you can operate it easily,
Smart APp Control: Use EV Smart Charger APp to control your chargerand manage charge times, schedule charging while you’re away,and optimize your charging to take advantage of off peak electricity
OCPP 1.6J: Our charger support complete OCpp1.6j protocol so it canachieve all smart charging function of OCPp1.6J, Offine chargingupload-Offine charging records will be synced to the OCppback endupon network recovery
Customization Access: Different authorization modes for private or shared use.
Connectivity: Equipped with WiFi, LAN, RFlD, and Bluetooth for flexibleand remote access.
Load balancing strategy: to automatically adjust the charging current of theEVSE and protect the home electrical circuit.
Safety and Durability
High performance charging control board of our best 22KW Wallbox iscompat-ible with all styles of electric vehicle charging. Leakage protectionUpgrade to Type A 30mA AC + 6mA DC (three phaseand lP65 waterproofand UV protection ABS casing ensure durability and safety.lt providescustomers with quality, securityand a friendly charging experience.
Share chargers with others by RFlD cards.White-label solution:
With our shared chargingstation solution, you can easily set up amanaged wallbox network for residential communities without limitation.We provide thecomplete system that allows you to monitor usage,control access, and handle billing seamlessly through a central app. Formultitenant use, our softwareensures transparent, per-user tracking of consumed energy (kWh),enabling easy and accurate invoicing directly via utility bills. it simplifieseverything from management to payment.
White-label solution:
Hardware: We customize everything- from your logo, labels and panelcolors to the overall -and can even tailor the packaging to match your brandidentity.
Software: Fully customization white-label EV charging software withbranded mobile app, web portal, admin backend, and secure datahostingperfect for CPOs, feet operatorsand real estate companies seekingsaleableCPMS solutions.
